                                                                                        Automatic mobile phone battery package machine

                                                                                        TS SP03

                                                                                        Automatic mobile phone battery package machine

                                                                                        The machine inserts the battery to the plastic bag and pack it automatically.

                                                                                        The bag material can be PE, PO, PP, CPE.

                                                                                        Adopt suck disc to move the battery, avoid scratches during the movement.

                                                                                        The bag can be sealed or not sealed.

                                                                                        Compact design,low energy consumption, liable and high productivity.

                                                                                        Easy operation and maintenance.

                                                                                        Adopt PLC and touch screen HMI, auto diagnosticate system.

                                                                                        Bags punching function is optional.



                                                                                        Tag:  Automatic mobile phone battery package machine



                                                                                        Specification

                                                                                        Dimension  Length

                                                                                        30-90 mm

                                                                                        Dimension  Width

                                                                                        30-90 mm

                                                                                        Dimension  Thickness

                                                                                        2-12 mm

                                                                                        Capacity

                                                                                        2000-2800 Pcs / H

                                                                                        Power input

                                                                                        200-240 VAC / 1 Phase / 50 Hz

                                                                                        Power

                                                                                        0.5 Kw

                                                                                        Air pressure requirement

                                                                                        0.4~0.6 MPa

                                                                                        Package dimension / weight

                                                                                        1100*800*750mm / 150Kg
